COB LED Ceramic (6 - 100 Watts)

COB LED Ceramic (6 - 100 Watts)
COB LED Ceramic (6 - 100 Watts)
Product Code : 03
Brand Name : Kwality
Product Description

Kwality Photonics is offering a huge range of COB LED Ceramic (6 - 100 Watts) for 35-50W, KLHC3609W for 6-9W, KLHC3622W for 22W, KLHC3622W for 10-22W & also KLHC36125W for 100Watts !. Prices at astonishing below Rs.7 per watt ! These LEDs have ceramics plus metal material with high thermal conductivity as the substrate and adopt silicon injection molding technology with good impervious performance, high reliability and very low degradation rate. Kwality COB POWER LEDs have very low thermal resistance long lifetime over 50000hrs. These LEDs are most applicable for general lighting sources and luminaries & can be operated with max junction temperature of 115°C.


35 - 50 Watts Cob Led Klhc3650W:


  • Power Watts : 35 - 50 Watts
  • Current : 1050 - 1440 Ma
  • Voltage Vf : 34-38 Volts
  • Lumen S : 4270 - 5300 Lumens
  • Size(Lxbxh) : 28 mm x 28 mm x 1.5 mm


Other Details:


  • The LED Chips in classic SMD packages are 3014 & 3528 LEDs.
  • The KLSL3228W delivers 8-9Lumens at 20mA (0.06W)
  • The KLSL3014W delivers 12Lumens at 30mA (0.1W)
  • The LED Chips in MOST POPULAR medium power SMD packages are 2835 & 5630 LEDs.
  • The KLSL2835W-26 delivers 24Lumens at 60mA (0.2W) & KLSL5630W & KLSL2835W-65 delivers 65 lumens at 150mA.
  • The High power LEDs like KLHP331W deliver 130lm & 145Lm respectively, in non-reflow grade. the 3Watt reflow grade emitters KLHP3433W of 280Lm & KLHP3535W gift you the flexibility of producing LED lights with just a simple soldering iron or with modern pick & place machine !


    Electrical Characteristics:

    Parameters

    Symbol

    Min

    TYP

    Max.

    Units

    Test Condition

    Forward Volteage

    VF

    34

    37.5

    40

    V

    IF=1.05A

    Luminous Flux

    øV

    4270

    4410

    5300

    Lm

    IF=1.05A/38Wtyp

    Color Temperature

    Tc

    --

    5700

    --

    K

    IF=1.05A

    Color Rendering Index

    CRI

    80

    --

    --

    Ra

    IF=250mA
